UCB

DESIGN. LED UNDER CABINET BULLNOSE LIGHT is perfect for a hidden backlight. The acrylic lens with a 115° beam angle and CRI90+ grants you even light distribution. It is designed to operate on 120V circuits.

COLOR SELECTABLE. You can choose either a 3000K warm white, 4000K cool white or 5000K daylight color temperature.

DIMMING. Smooth triac dimming capabilities ranging from 10% to 100% with modern LED dimmers allow you to control the look and feel of your space.

INSTALLATION. Quick and easy hardwired installation. It is also Damp Locations rated.

ADVANTAGES: With a lifespan of 50,000 hours, these fixtures are made to last decades under normal operation! ASD provides a 5-year limited warranty along with ETL and Energy Star certifications to guarantee top quality products and safety!

AVAILABLE FINISHES:

CRI90+ Rich and natural colors
3 color temperature options
Seamless triac dimming to adjust brightness level and save energy
Quick and easy hardwired installation

Available
Power

5-24W

Color
temperature

3CCT

DOWNLOADS:

ETL

5 year warranty

Finish

All

Bronze

White

Wattage

All

5

8

12

16

20

24

3

Voltage

All

120

ASD LED Under Cabinet Bullnose 12inch 5W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, Bronze ETL

ASD-UCB-12D5CC-BZ

UPC 81012811066
Certification ETL
Finish Bronze
Material Aluminum, Plastic
Voltage 120
Power 5
Luminous Flux 302 / 318 / 325

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP22
Warranty 5
Dimensions DxH 3 11/16 x 12 x 1 1/8

Downloads

IES (PDF)

IES

ASD LED Under Cabinet Bullnose 12inch 5W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-12D5CC-WH

UPC 81005073461
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 5
Luminous Flux 335 / 352 / 354

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 12 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 12inch 5W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL 2pack

ASD-UCB-12D5CC-WH-2PACK

UPC 81012811229
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 5
Luminous Flux 335 / 352 / 354

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 12 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 18inch 8W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL 2pack

ASD-UCB-18D8CC-WH-2PACK

UPC 81012811230
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 8
Luminous Flux 597 / 640 / 633

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 18 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 24inch 12W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, Bronze ETL

ASD-UCB-24D12CC-BZ

UPC 81012811068
Certification ETL
Finish Bronze
Material Aluminum, Plastic
Voltage 120
Power 12
Luminous Flux 754 / 794 / 800

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP22
Warranty 5
Dimensions DxH 3 11/16 x 24 x 1 1/8

Downloads

IES (PDF)

IES

ASD LED Under Cabinet Bullnose 24inch 12W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL 2pack

ASD-UCB-24D12CC-WH-2PACK

UPC 81012811231
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 12
Luminous Flux 827 / 860 / 859

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 24 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 32inch 16W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, Bronze ETL

ASD-UCB-32D16CC-BZ

UPC 81012811069
Certification ETL
Finish Bronze
Material Aluminum, Plastic
Voltage 120
Power 16
Luminous Flux 1083 / 1130 / 1130

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP22
Warranty 5
Dimensions DxH 3 11/16 x 32 x 1 1/8

Downloads

IES (PDF)

IES

ASD LED Under Cabinet Bullnose 32inch 16W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-32D16CC-WH

UPC 81005073465
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 16
Luminous Flux 1048 / 1104 / 1121

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 32 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 40inch 20W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-40D20CC-WH

UPC 81005073466
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 20
Luminous Flux 1454 / 1574 / 1558

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 40 x 1 1/8

Downloads

IES (PDF)

IES

ASD LED Under Cabinet Bullnose 48inch 24W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-48D24CC-WH

UPC 81005073467
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 24
Luminous Flux 1630 / 1758 / 1695

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 48 x 1 1/8

Downloads

IES (PDF)

IES

ASD LED Under Cabinet Bullnose 9inch 3W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-9D3CC-WH

UPC 81005073460
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 3
Luminous Flux 189 / 199 / 201

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 9 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 18inch 8W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, Bronze ETL

ASD-UCB-18D8CC-BZ

UPC 81012811067
Certification ETL
Finish Bronze
Material Aluminum, Plastic
Voltage 120
Power 8
Luminous Flux 655 / 708 / 715

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP22
Warranty 5
Dimensions DxH 3 11/16 x 18 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 18inch 8W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-18D8CC-WH

UPC 81005073463
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 8
Luminous Flux 597 / 640 / 633

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 18 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose 24inch 12W 120V Triac 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCB-24D12CC-WH

UPC 81005073464
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 12
Luminous Flux 827 / 860 / 859

Dimming Y
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 24 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose with Power Outlet 18inch 8W 120V 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCBS-18N8CC-WH

UPC 81005073880
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 8
Luminous Flux 655 / 708 / 715

Dimming N
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 18 x 1 1/8

Downloads

IES

IES (PDF)

ASD LED Under Cabinet Bullnose with Power Outlet 24inch 12W 120V 3000/4000/5000K Hardwired, On/Off Switch, White ETL

ASD-UCBS-24N12CC-WH

UPC 81005073881
Certification ETL
Finish White
Material Aluminum, Plastic
Voltage 120
Power 12
Luminous Flux 769 / 816 / 822

Dimming N
Color Temperature 3000/4000/5000
Location Damp
IP IP20
Warranty 5
Dimensions DxH 3 11/16 x 24 x 1 1/8

Downloads

IES

IES (PDF)
